the legend returns. You asked – ritchey listened. Back by popular demand, the ritchey p-29er makes its triumphant return to the trails.
A modern manifestation of tom ritchey’s deep mountain biking heritage, the p-29er is designed for fast, technical cross-country singletrack. Built from ritchey’s proprietary triple-butted logic steel and featuring progressive XC geometry, it delivers a perfectly balanced ride—responsive and snappy, yet comfortable and composed.
From roots and rocks to endless ribbons of singletrack, the p-29er is a celebration of everything great about mountain biking. With boost spacing, stealth dropper routing, and compatibility with 100mm forks, it’s a forward-thinking frame with old-school soul.
Features
- triple-butted ritchey logic steel tubing
- modern XC geometry for a balanced and lively ride
- internal stealth dropper routing
- boost 148mm rear spacing
- tapered head tube and threaded bottom bracket
- tyre clearance for up to 29x2.3”
- 100mm travel suspension fork or 483mm rigid fork compatible
- post-mount rear brake with 160–180mm rotor support
- external cable routing and replaceable stainless-steel derailleur hanger
specifications
frame material: heat-treated, triple-butted ritchey logic steel, tig welded
headset: wcs headset included (upper is42/28.6, lower is52/40)
headset upper bearing: 41.8mm od / is42/28.6
headset lower bearing: 51.9mm od / is52/40
seatpost diameter: 27.2mm with stealth dropper post routing
seat clamp size: integrated (2.5nm max for chain guides – 28.6mm clamp)
bottom bracket: 73mm bsa threaded
crankset ring max: 38t single, 1x specific
chainline: 52mm
direct mount compatibility: not compatible (t-type derailleurs/cassettes not supported)
bottle cage mounts: two (downtube and seat tube); size s has downtube only
rear spacing: boost 148mm, 12mm alloy thru-axle included
cable routing: external
derailleur hanger: replaceable stainless steel
fork compatibility: 100mm boost suspension or 483mm axle-to-crown rigid
wheel/tyre compatibility: 29 x 2.25” (2.3” max; dependent on tyre and rim brand)
brake mount: post mount, 160mm standard / 180mm max with adaptor
sizes: s (15”), m (17”), l (19”), xl (20.5”)
frame weight: 2,315g (m/17”)
